Category |
Data |
Maximum fluid working pressure |
360 psi (25 bar) |
Air input pressure operating range |
30-180 psi (2-12 bar) |
Pump cycles per 1 gallon (3.8 liters) |
40 (50 for Model 223954) |
Maximum recommended pump speed for continuous operation |
100 cycles per min |
Air consumption |
Approx. 3 scfm (0.09 m#/min) at 1 gpm (3.8 liters/min) at 100 psi (7 bar) air pressure |
Maximum Ambient temperature for T6 hazardous location use |
120°F (50°C) |
Maximum operating temperature of fluid pump |
480°F (248°C) for non–hazardous location applications only |
Maximum operating temperature of air motor |
280°F (138°C) for non–hazardous location applications only |
Wetted parts |
Stainless Steel, PTFE, Polyetheretherketone (PEEK) |
Overall length |
30.5 inches |
Weight |
15 lbs.25 |
