Product Manuals / Related PDFs:

Hot Coat™ Plus 16 Product Manual is available from Glue Machinery Corporation - 1-888-202-2468

Hot Coat™ Plus 16 Precision Industrial Hot Melt Roll Coater

$

Product Details:

Item Machine Specifications
Power Supply Demand 220 VAC / 50-60 Hz
Power 3 KW
Size (L x W x H: inches) 25.2" x 13" x 17.5"
Roller Width 16.125"
Tank Capacity (lbs) 6.5 lbs
Max Viscosity 20,000 CPS
Max Melt Rate 8.5 lbs/hr
Max Working Temp. 428ºF (220ºC)*
*Max operating temperature of 428°F with a factory set (adjustable) low temperature motor enable/lockout out of 212°F
  •  Variable speed motor drive.
  • Adjustable temperature controls for melter.
  • Melter is manually cycled to fill wheel.
  • Adjustable doctor blade.
  • Variable width product.
  • Driven nip roll.
  • Easy access to tank for removal of debris from substrates.
  • Bulk Filling Systems with automatic level control available.
  • Parts and service available with one call.
  • Hot Coat 16/Plus Power Requirements: 240VAC= 12.5 amp/1ph/50-60Hz.
  • 7'8", 12 Gauge Power Cable Included to NEMA L6-20 240V/20amp plug.
